Spitfire 110 DC Solar Water Pump

Spitfire 110 DC Solar Borehole Pump & Controller - 750W, 100m Head

The Spitfire 110 is a 750W DC solar submersible pump designed for borehole and well water pumping on off-grid farms, smallholdings, and rural properties across Southern Africa. It runs directly off solar panels, no batteries or grid power needed, and can lift water from depths of up to 40m below static water level, delivering up to 3.6m3 of water per hour at heads of up to 100m. It comes paired with a matched DC controller for plug and play solar input.

Specifications:

Power Rating: 750W
Max Head: 100m
Max Flow Rate: 3.6m3/h
Max Submersion Depth: 40m
Voltage Range: 90V to 160V, optimal 150V (160V max - do not exceed)
Outlet Size: 25mm
Pump Diameter: 90mm
Power Source: DC Solar, controller included

Well Sensor NOT included. Purchase separately.

Best suited for livestock watering, household water supply, small scale drip irrigation, and borehole or well pumping in off-grid or load-shedding-prone areas.

Frequently Asked Questions

How deep can the Spitfire 110 pump water from?
The Spitfire 110 can be submerged up to 40m below the water surface and is rated to lift water through a total head of up to 100m.

What size solar panel do I need for the Spitfire 110?
2 x 450 - 500w

Can I install batteries?
No. It is a direct solar DC pump. It runs straight off solar panels via its DC controller without requiring batteries.

What is the flow rate of the Spitfire 110?
Up to 3.6 cubic metres per hour, depending on total head and solar input at the time.

What outlet size does it use?
A 25mm outlet, standard for most rural and agricultural piping setups.
